SPECIFICATIONS

Panel Thickness: Ø16.20mm

Function:ON-OFF Latching  (ON)-OFF  Momentary

Contact Rating:  lth 3A/250VAC  resistive load 3A/125VAC

                                  lth 5A/250VAC  resistive load 5A/125VAC

                                  lth 10A/250VAC  resistive load 10A/125VAC

                                  lth 16A/250VAC  resistive load 16A/125VAC

Mechanical Life: Momentary 100,000 cycles    Self-lock 50,000 cycles

Electrical Life: 50,000 make-and-break cycles at full load

Torque: 5~14Nm

Travel: About 3.5mm±0.5mm

Operation Pressure: 700gf±200gf

Contact Resistance: 50 mΩ max.

Insulation Resistance: 100MΩ min.

Dielectric Strength: 3,000 Vrms @sea level.

Operating Temperature: -20°C to 85°C
