SPECIFICATIONS

Panel Thickness: Ø25.20/30.20mm

Function:ON-OFF Latching  (ON)-OFF  Momentary

Contact Rating: lth 3A/250VAC  resistive load 3A/125VAC

                          lth 5A/250VAC  resistive load 5A/125VAC

                          lth 10A/250VAC  resistive load 10A/125VAC

                          lth 16A/250VAC  resistive load 16A/125VAC

Mechanical Life: Momentary 100,000 cycles    Self-lock 50,000 cycles

Electrical Life: 50,000 make-and-break cycles at full load

Torque: 5~14Nm

Travel: About 3.5mm±0.5mm

Operation Pressure: 700gf±200gf
Contact Resistance: 50 mΩ max.
Insulation Resistance: 100MΩ min.

Dielectric Strength: 3,000 Vrms @sea level.
Operating Temperature: -20°C to 85°C
